Phaeton Galaxy 2.5M UV Flatbed Printer UD-2512UFW CMYK+W

Phaeton Galaxy 2.5M UV Flatbed Printer UD-2512UFW CMYK+W

1, CYMK+W , Max. printing width : 2,500mm x 1,260mm

2, Convenient Useful Tools for Signage

3, High Precision High Quality

4, No Pate, Direct Printing on Substrate

5, 1440dpi High resolution, CMYK 4 color + White printing

6, Suitable for both indoor and outdoor printing

Galaxy UD-2512UFW

Galaxy UD-2512UFW

Phaeton Galaxy 2.5M UV Flatbed Printer UD-2512UFW CMYK+W

Phaeton Galaxy 2.5M UV Flatbed Printer UD-2512UFW CMYK+W

Convenient Useful Tools for Signage

High Precision High Quality

No Pate, Direct Printing on Substrate

MODEL UD-2512UFW
Printhead Epson DX5
Number of printhead 1 Head (CMYK or CMYKW)
Output Quantity (m2/h) Print Mode Outputs(m2/h)
Draft 6Pass 11
Standard 8Pass 8
Quality 12Pass 5
High Quality 16Pass 4
Max. printing width 2,500mm x 1,260mm
Max. media width 2,500mm x 1,260mm
Ink Type UV Ink
Color 5 Color (C,M,Y,K,W)
Volume 1L per main tank of each color
Ink supply system Auto ink supply system
Media Width 1,260mm
Type PS Board, KT Board, PVC Foam Board, Acrylic, Aluminum, Glass, etc
Cleaning System Auto Cleaning System
Print Interface USB 2.0
Printhead Height 1 to 40mm from Media
Input Power AC 220V/230V, 50Hz/60Hz
Printer Power 154W
Vacumm Power 4,000W
Printer Dimension/Weight L3,871 x W2,165 x H1,190mm / 525KG
Package Dimension/Weight L4,150 x W2,050 x H1,550mm / 955KG

Photos

Phaeton Galaxy UD-2512UFC UV Flatbed Printer - 4 color AllSign Printer -Phaeton Galaxy UD-2512UFC UV Flatbed Printer Phaeton Galaxy UD-2512UFC UV Flatbed Printer - 4 color AllSign Printer -Phaeton Galaxy UD-2512UFC UV Flatbed Printer Phaeton Galaxy UD-2512UFC UV Flatbed Printer - 4 color AllSign Printer -Phaeton Galaxy UD-2512UFC UV Flatbed Printer Phaeton Galaxy UD-2512UFC UV Flatbed Printer - 4 color AllSign Printer -Phaeton Galaxy UD-2512UFC UV Flatbed Printer

Phaeton Galaxy UD-2512UFC UV Flatbed Printer - 4 color AllSign Printer -Phaeton Galaxy UD-2512UFC UV Flatbed Printer Phaeton Galaxy UD-2512UFC UV Flatbed Printer - 4 color AllSign Printer -Phaeton Galaxy UD-2512UFC UV Flatbed Printer Phaeton Galaxy UD-2512UFC UV Flatbed Printer - 4 color AllSign Printer -Phaeton Galaxy UD-2512UFC UV Flatbed Printer Phaeton Galaxy UD-2512UFC UV Flatbed Printer - 4 color AllSign Printer -Phaeton Galaxy UD-2512UFC UV Flatbed Printer

The picture is only for reference,please make the object as the standard.
The Speed data varies in different computer.
Inkjet printer prints with fine ink dots, so the printing colors may be different along with the chnage of printheads. When printing with serveal printers at the same time, a difference in printing colors may exists due to a difference exist in every single printer.
But as far as we know, most for the operation is similar for different printer.


If the video can't play, also can watch the video on Facebook or Vimeo.

Videos on Facebook

facebook.com/GalaxyPrinter/videos

facebook.com/SolventPrinter/videos

Videos on Vimeo

https://vimeo.com/printers

NINGBO ALLSIGN TRADING CO.,LTD is an enterprise with the experiences of 12 years for international signs industry by serving high end users and agents.

AllSign established in 2003,head quarter located in Ningbo,China, AllSign provide full range of products and services for signs industry and our products range is from indoor/outdoor large format printing spare parts,accessorie. With our professional experiences and solid cooperation with Galaxy, Infiniti/Challenger, Phaeton Printer, AllWin Printer, Myjet Printer and Printer Spare Parts for China Printer and Epson, Roland, Mimaki,Mutoh, HP parts, and other top brands of printing equipments service and support center, we have been serving users from more than 63countries. .

Who Bought From Us for you reference:

Printhead & Printer Parts Order by Express

Bulk Order by Container Shipping

We have been sending goods to the world wide including:

For Parts by courier:
I. American areas(USA,CA,MEXICO,Trinido Tobago,etc); 2-4days.
II. South American areas(Brazil,Chile,Agerntina,Wulagui,etc), 3-5days.
III. Australian areas(Australia,New Zealand,Solomen,etc); 2-3days.
IV. Europen areas(UK,Germany,Franch,etc). 2-3days.

By TNT/DHL/UPS/FEDEX for door to door services. We are with a professional logistic team working for the shipment for fastest ,safetest and most ecnomical shipping methods for different areas.

Select the right parts for your machines by machine models in our product list.
Make a list for what you need and send to our service team Please try your best to send us the full information of you(full address,tel,zip code,tel,full name).
If you are from Brazil,please offer us the CNPJ code. Service team will find the best way for the shipment and send you the PI with the full information;

(1) Place an order to AllSign;

(2) Get the bank account information of AllSign;

(3) Make the payment at the bank, and get the Payment Receipt;

(4) Send the Payment Receipt to us;

(5) Receive the Tracking Number of your order(For parts),If for bulk order is by the B/L;

(6) Wait for your order.

You may use the following methods of payment: PayPal online payment, PayPal direct payment, credit card (through PayPal gateway, some areas may be restricted), bank transfer, and Telegraphic Transfer (T/T) payment and Western Union Payment.

For details, please refer to the following:

Payment terms:
paypal We accept PayPal (Need PayPal Fees).
Our PayPal account:
Notice: PayPal Fees for China Account: https://www.paypal.com/c2/webapps/mpp/paypal-fees
western union FIRST NAME: LAST NAME: FAN
Address: NINGBO, CHINA
TT
  • For small amount payment (Spare parts,shipping cost,consumables,samples,etc).
Beneficiary's Bank: YINZHOU BANK
SWIFT BIC: YZBKCN2N
ADD: No.88, Min Hui Xi Road, Yinzhou District, Ningbo,China
Beneficiary's A/C no: NRA81011614505004258
Beneficiary: MEC Industry And Trade Co., Ltd.
ADD: NO.106,Building 14,NO.818,Qiming RD., Yinzhou District,Ningbo, P.R.China
Intermediary Bank:WELLS FARGO BANK, N.A. NEW YORK
SWIFT BIC: PNBPUS3NNYC

  • For general payment (Machines or For the purchasing order over 10,000USD.)
Beneficiary's Bank: YINZHOU Bank
SWIFT BIC: YZBKCN2N
ADD: No.88, Min Hui Xi Road, Yinzhou District, Ningbo,China
Beneficiary's A/C no: 81011614301114313
Beneficiary: NINGBO ALLSIGN TRADING CO.,LTD.
ADD: NO.106,Building 14,NO.818,Qiming RD., Yinzhou District,Ningbo, P.R.China
Intermediary Bank: WELLS FARGO BANK,N.A.NEW YORK
SWIFT BIC: PNBPUS3NNYC

We will send you a payment confirmation email upon receiving your payment, and start arragne your order.

For PayPal,Western Union,Moneygram,we can get your payment in one day

For T/T payment, we always need 2-6days to receiving your payment depends on different countries

Normally speaking, we will spend 1 or 2 days to prepare the order and if it requires longer time, we will inform you as soon as possible. The general shipping time will be 3 to 6 days. Therefore, under normal situation, you will receive the items in 4 to 9 days.

If you choose to ship by sea, generally the shipping time is between 10 and 30 days, depending on the consignee address.

For the items you purchased online, we will arrange international express delivery to ship and usually the carriers are FedEx, TNT, UPS, DHL, or EMS.

It shall be quite safe during shipping with substantial packing.

1) Our service team will send pictures for all the goods in your order for confirmation.
2) The tracking number will be sent to you immediately once shipper took away the parts.
3) Track the goods on express companies official sites(www.dhl.com / www.fedex.com / www.ups.com / www.tnt.com) until you get the goods.
4) You also can track your package from our website:

printer parts Shipping by Express

bulk order Shipping By Container

a). Changes & Returns:

The item can be returned under the following conditions:

1) There is found quality problem after opening the package.

2) The item is different from the order list.

3) There is obviously design flaw on the product.

4) Products can not be used because of design flaw.


Returned items are regarded as invalid under the following conditions:

1) The item still works even though there's damage during transportation.

2) No claim is made up to 7 days after the customer has received the products.

3) The item is returned because of different color or packaging which has no effect to the product.

4) The returned item does not meet the conditions.


Note: 1) The returned item will only be exchanged with a same style item; If such item is out of stock, it is acceptable to exchange with other item from our website but in same value.

2) The returned item should be undamaged and in their original packaging.

3) Please provide the following information when returning the products: products' names or codes, the problems encountered, and your order record.

4) All the printhead can't changes & Returns.We just promise all the printhead is the original new heads from factory.

5) The return transportation fee will be equally covered by both parties.


Returning procedure:

If a serious problem is found within 7 days of receiving the products, you should contact Customer Service and our staff will help you find a solution in 2 weekdays' time.


b). Warranty:

For the Equipments, such as printer, engraving machine sold via www.UDPrinter.com, we provide 12 months warranty after shipment.

Notes: The Ink supply System parts include all kinds of Printhead without guarantee.

For more information, please refer to "Customer Service & Warranty" on our website http://www.UDPrinter.com/How-to-Order/
