Digital Printing Machine CK3208S / CK3204S with Konica KM512 Printhead

Digital Printing Machine CK3208S / CK3204S with Konica KM512 Printhead

Download the PDF Catalogue for Konica Solvent Printer CK3208



◆Japanese Konica 512LN printhead , 512 individually addressable nozzles

◆Excellent mechanical structure and humanization design ,Removable, safe and economical of transportation

◆Three-stage adjustable temperature heating for media

◆The Skip White can highly improve the production efficiency.

◆The Border Feather can eliminate the cross grain which engendered while printing



Brand Sparepart Standard Setup
UMC-KM512-8H Boards (BYHX Optional)
Honsoft UltraPrint RIP software
Leadshine 180W servo motor For X and Y motion
Germany IGUS drag train
Germany IGUS Power cable
Italy Megadyne belt
American Value Plastics tube connector
Taiwan Hiwin linear guide with two pcs mute slider
JYY DC ink Pump
Classic Printer body
High quality 171mm wide printing bed
One row big power AC drying fans
LED lights at cleaning postion and printing bed
4 in 1 heating control system
Rear-Printing bed-front-Printhead heater
Separate ink purging system
Lift type carriage
Unique printhead protection stack
Multifunction Feeding system

Printing Speed:
2pass-80㎡/h-180*720dpi
2pass-60㎡/h-240*720dpi
3pass-52㎡/h-180*1080dpi
3pass-40㎡/h-240*1080dpi
4pass-40㎡/h-180*1440dpi
4pass-30㎡/h-240*1440dpi

Specification:

Item Parameter
Printhead Model CK3204 / CK3208
Printhead KM512LN Printhead
Number of Head 4PCS / 8PCS
Printhead Hight 2mm-4mm Media Adjustable
Ink Ink Color CMYK(4 color)
Ink Type KM512LN special ink
Ink Supply Auto ink supply system
Ink Supply Detecting System Lack of Ink Supply Detecting System
Heating type Heating System Front,Back,Bed Heater
Heating Temperature Normal Temperature~800C,Suggestion Temperature: 40~650C
Drying Sytem Equipped Drying Fan
Media Print Width 3200mm(max)
Media Type Banner, Flex ,PVC,Mesh ,Adhesive vinyl,PP paper ect
Media Feeding Photoelectricity Sensor and Automatic Feeding System
Print Speed Standard Quality 180x720 2pass, 80m2/h/
High Quality 180x1080 3pass, 52m2/h/
Ultra Quality 180x1440 4pass, 40m2/h
Print interface USB Interface
Temperature and Humidity Temperature:180C~290C Humidity:50~80%
Rip software PhotoPrint DX10.5;UltraPrint
Input power Voltage:AC220V,Frequency:50HZ
Package Dimension L*W*H(mm)4700*1030*1540 / 850kgs)
L*W*H(mm) 4630*760*1100(Separate Package-1)
L*W*H(mm) 990*520*670(Separate Package-2)

The Speed data varies in different computer.
Inkjet printer prints with fine ink dots, so the printing colors may be different along with the chnage of printheads. When printing with serveal printers at the same time, a difference in printing colors may exists due to a difference exist in every single printer.


AllSign Konica Printer Advantages

Photos

Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208/CK3204 Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208/CK3204 Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208/CK3204 Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208/CK3204

Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208/CK3204 Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208/CK3204 Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208/CK3204 Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208/CK3204




Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer CK3208S/CK3204S. Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Feeding System. Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Unique printhead protection stack . Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- LIFT TYPE Carriage.




Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer Front side. Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Front side. Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Back Side. Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Back Side.

Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Blue Color. Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Blue Color. Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Blue Color. Konica Printer CK3208 with 8pcs Konica 512/42pl printhead AllSign Printer - Konica Printer- Blue Color.

The picture is only for reference,please make the object as the standard.
The Speed data varies in different computer.
Inkjet printer prints with fine ink dots, so the printing colors may be different along with the chnage of printheads. When printing with serveal printers at the same time, a difference in printing colors may exists due to a difference exist in every single printer.
But as far as we know, most for the operation is similar for different printer.
